Bicycle technical specifications
Frame and suspension
Frame:
Aluminium 6061, boost, 120 mm
Shock:
RockShox Deluxe Select, air, 210x50 mm
Fork:
RockShox Psylo Silver RC, air, 130 mm, tapered
Drivetrain
Speeds:
12
Drivetrain system:
1x12
Drivetrain type:
External
Rear derailleur:
Shimano Deore XT, RD-M8100, Shadow Plus, 12-S
Shifters:
Shimano Deore, SL-M6100, Rapidfire Plus
Crankset:
Shimano Deore, FC-M6100, 32T
Cassette:
Shimano CS-M6100, 10-51T
Chain:
Shimano CN-M6100
Brake system
Brakes:
Magura MT5, 4-piston, hydr. disc brake
Cockpit
Handlebar:
Raymon Riser 31.8 mm, Sweep: 9 °, Rise: 15 mm
Stem:
Raymon 31.8, 0 °, Ahead
Grips:
Raymon Ergo, lock on
Headset:
Raymon ZS44/ZS56
Wheels
Wheel size:
29"
Wheelset:
Raymon VR23/DT210, 15x110/12x148 mm
Front tire:
Schwalbe Nobby Nic, Performance, 57-622, 29x2.25
Tires:
Schwalbe Nobby Nic, Performance, 57-622, 29x2.25
Saddle and components
Saddle:
Raymon HM Fit
Seat post:
Raymon, 31,6 mm, Dropper Post
Seat post clamp:
34,9, hex screw
Weight and dimensions
Weight:
16,4 kg
Maximum load (rider+bicycle):
120 kg
Frame geometry
- Seat tube length: 370 mm
- Reach: 420 mm
- Stack: 610 mm
- Top tube: 560 mm
- Steering angle: 66 mm
- Seat tube angle: 77 mm
- Head tube: 100 mm
- BB drop: 50 mm
- Wheelbase: 1170 mm
- Chain stay: 455 mm
- Crank length: 114 mm
- Stem length: 40 mm
- Handlebar width: 780 mm
- Seatpost drop: 125 mm
- Ground clearance: 250 mm
